Optical Fiber Distribution Box

Wall / Pole Outdoor Fiber Optic Distribution Box

16 cores Optical Fiber Distribution Box, wall/pole outdoor fiber optic distribution box

Fiber Optic Distribution Box is often deployed in FTTH applications for connecting feeder and distribution cables through optical splitters. And it can distribute cables after installing splitters and also can draw out room fiber optic cables in direct or cross-connections. The splitter termination box is suitable for the fiber terminal point to complete connection, distribution, and scheduling between perimeter fiber cables and terminal equipment.

The Optical Fiber Distribution Box is made of high-strength engineering plastics with strong UV and aging resistance. The distribution box is sealed with a snap-on + two-screw structure, and the shell is opened by flipping left and right. It can accommodate 16 SC adapters and 3 1:8 blockless splitters or 2 1:8 cassette splitters, and 1 16-core splice tray. The maximum capacity is 16 cores.

Good Low Back Reflection & High Return Loss, This fiber optic pigtail Each insert performance is formance higher than standard requirements in the industry, good temperature stability. Set of Accessories is Complete and The Optical Fiber Couplers is Configured and Fiber Pigtail cables are inserted neatly.

● Material: PC+ABS, wet-proof, water-proof, dust-proof, anti-aging, protection level up to IP65.

● Clamping for feeder cable and drop cable, fiber splicing, fixation, storage, distribution...etc all in one.

● Cable, pigtails, and patch cords are running through their own path without disturbing each other, cassette type SC adaptor installation, is easy maintenance.

● The distribution panel can be flipped up, feeder cable can be placed in a cup-joint way, easy for maintenance and installation.

● The cabinet can be installed by the way of wall-mounted or poled-mounted, suitable for both indoor and outdoor uses.
