FC-LC Single Mode Fiber Optic Patch Cord
Products Description
1. Fiber optic patch cords are available in all standard connector styles, all standard fiber types and all standard cable configurations to meet all your interconnection needs. They are available in any length.
2.The patch cord are factory terminated, assembled, tested and inspected prior to shipment.
3.All patch cords are manufactured using OFNR riser grade cable, LSZH, plenum, and premium customized specs available upon request, and 100% factory tested to ensure the performance to meet TIA/EIA-568-8-2, iso11801:2002 and EN 50173-1 standards. All assemblies are tested to meet Telcordia GR326-CORE.
Reference
|
Model |
SM |
MM |
|
Connector Fiber Count |
1,2,4,8,12 core |
|
|
Polish |
PC, APC |
|
|
Housing Color |
Standard (green), |
Standard(Beige) |
|
Insertion Loss Standard type |
less than 0.7dB |
Less than 0.5dB |
|
Insertion loss Elite type |
Less than 0.35dB |
Less than 0.3dB |
|
Return Loss |
PC >50dB, APC>60dB |
>30dB |
|
Durability (500 matings) |
less than 0.2dB |
less than 0.2dB |
|
Test Eavelength |
1310/1550nm |
850/1300nm |
Products Details
FAQ
Q:What is the difference between a patch cable and an Ethernet cable?
A:Ethernet patch cables are a specific type of patch cable used for transmitting data via the internet. Not all patch cables are Ethernet cables, but most Ethernet cables can be considered patch cables.
Q:Can I use a patch cable to connect to the internet?
A:Yes, but only if it's an Ethernet cable. One end must be plugged into a router or a network hub that is connected to a modem. You can use Ethernet patch cables to connect your router to a modem.
---------------------------------------------------------------------------------------------------------------------------------------------------------
