Waterproof FDB Box

Waterproof FDB box Fiber Optic Terminal Distribution Box





Material	PC+ABS
Protection Level	IP65
Suitable Adapters	SC, LC
Mounting Method	Pole / Wall
Cable Inlet	2 Ports
Fiber outlet	16 Ports
Max Fiber capacity	16 Cores
Applications	FTTH, FTTB, CATV
Max Capacity	16pcs sc adapter: 2pcs 1x8 or 1pcs 1x16 or 1pcs plug-in PLC splitter
OEM	Support





The equipment is used as a termination point for the feeder cable to connect with drop cable in FTTx communication network system. The fiber splicing, splitting, distribution can be done in this box, and meanwhile it provides solid protection and management for the FTTx network building.



This type of Waterproof FDB Box can accommodate up to 9 users. It is used as the termination point for the connection of feeder cable and lead-in cable in FTTx network system. It integrates fiber splicing, splitting, distribution, storage and cable connection in one sturdy protective box.



▶Apply to wall-mounted Hold-up and pole-type installation

▶ High-strength material with good weather adaptability and UV resistance.

▶Port into the end and leakage design, no need to open the box, easy construction.

▶Internal multi-wiring, can be independent or combined with different types of PLC Splitter.

▶Corning,Huawei and conventional waterproof adapters can be installed, And these adapters can be distinguished by different colors

▶Ultrasonic welding, excellent sealing performance, Waterproof to IP68.



JP-I2-16OB fiber access termination box is able to hold up to 16 subscribers. It is used as a termination point for the feeder cable to connect with drop cable in FTTx network system. It integrates fiber splicing, splitting, distribution,storage and cable connection in one solid protection box





The bottom shell and the upper cover are welded by hot plate and cannot be disassembled... Pre-connection technology, plug and play. Moisture-proof, waterproof, dust-proof and anti-aging.



The box is not only used in waterproof situations, but also can be used for indoor cable deployment by replacing ordinary carefiber adapters and kits.



The optical splitter terminal box is a box used to install and use the optical splitter. It is made of cold-rolled plate, stainless steel, SMC, ABS and other materials.



The optical splitter junction box adopts a modular plug-in design with 2 to 4 expansion slots. Insert the optical splitter plug into the slot and it can be used. The expansion of the port is achieved by flexibly increasing the number of optical splitter plug-ins. Photon modules of different capacities are universal and interchangeable. It has the functions of splitting and wiring scheduling, and is widely used in corridors, basements, computer rooms and building exterior walls.







whole enclosed building.
Material: PC, IP65-rated protection, anti-aging, wet-, water-, and dust-proof.
Fiber splicing, fixation, storage, distribution, clamping for feeder and drop cables, etc., are all combined into one.
Easy maintenance, cassette-style SC/LC/PLC adaptor installation, cable, pigtails, and patch cables all follow their own paths without interfering with one another.
The feeder cable may be positioned by the expression port, the distribution panel can be flipped up, and installation and maintenance are simple.
Both wall-mounted and pole-mounted cabinet options are available, making them appropriate for both indoor and outdoor applications.





1. Wall-mounted
Using a percussion drill, drill two holes in the wall, knock into the metal tube, reinstall the case in the proper punching position on the wall, and tighten the screw completely, depending on the size of the hanging wall.

2. Pole-mounted
One set of simple pole rings should be fastened to the telecom pole.

3. Airborne
One, the cable connector box parallel to the pole, is fastened to the pole.
The cable connection box, which is parallel to the cable, is fastened to the cable.
