16 Core Fiber Optic Splice Closure

16 core Fiber Optic Splice Closure

Optical fiber splice closure is a connection part that connects two or more fiber optic cables and has protective components. It must be used in the construction of fiber optic networks and is one of the very important pieces of equipment. The quality of the optical fiber splice closure directly affects the quality and service life of the fiber optic network.

This inline fiber optic splice closure can be used as cable distribution box that used for optical splitting, fiber splicing, cable joint and distribution. It suits the cable distribution of optical communication equipment. The box has 2 ports on both ends and there is a removable plate with 16 exit points for the connection of pigtail and splitter, and it can provide different cable solutions for users.

As a cable distribution box, it can achieve optical cable distribution through connecting internal adapter with drop cable to lead out the optical signal, also applies to the protective connection of cables and pigtails; The enclosure has a unique 3-layer structure, upper for splitting and distribution, The middle for splicing and wiring, The lower for fiber storage; the upper layer plate can be flipped up ≥180 which is convenient to install and maintain. It can achieve direct or branch cable connection. The box allows the installation of up to 16 subscribers, can hold 24 core fusion splices.

When taking out the upper plate, the fiber enclosure can be used as inline splice closure; it is used for direct and branch connection during optical fiber transmission and provides cable joint connection protection. The inline closure can install 3 splice trays for 72 fiber splice.

●Has an electrical disconnection function for the incoming or outgoing cable.

●Can be re-opened and expansion ability.

●Used two-time pressure technology, to ensure no additional attenuator of closure.

●Made of high-quality engineering plastics.

●Suitable for single-core fiber cable and ribbon fiber cable.

●Tensile with tightness:2000N(axial), no leaking out.

●Dielectric strength:15V(DC).

●Impact: 16N*m(three times), no cracking, no leaking out.

●Comply with YD/T814-1996 standard.

Fiber termination box is universally used in telephone, agricultural telephone network systems, data, and image transmission systems, CATV cable television series, indoor cable through force access, and branch connection. A fiber termination box is available for the distribution and termination connection for various kinds of fiber optic systems, especially suitable for mini-network terminal distribution, in which optical cables, patch cores, or pigtails are connected. In addition to that, a fiber termination box can be applied to joint fiber pigtails, protect fiber optic splices and share out the connectivity with individual customers.

We sincerely invite you to send us an inquiry for further details.
